Honeywell Versatilis Transmitter
Honeywell Versatilis Transmitter
Configuration Required -Contact ISS
Honeywell Versatilis™ Transmitter is a multi-variant sensing platform based on the latest LoRaWAN® protocol communication technology. Low power consumption and easy installation helps manufacturers to deploy it at a scale while keeping OPEX low.
| MEASUREMENT PARAMETERS: |
| Surface Temperature |
| Ambient Humidity |
| Ambient Pressure |
| Vibration |
| Audio Acoustics |
|
Ambient Temperature |
| PARAMETER | DESCRIPTION | |||||||||||||||||||||||||||||||||||||||
| Measuring Parameters | Vibration, Acoustics, Surface Temperature, Ambient Temperature, Humidity, and Ambient Pressure | |||||||||||||||||||||||||||||||||||||||
| Measurement interval (Sensor Parameters) | 1 min to 60 mins | |||||||||||||||||||||||||||||||||||||||
| Vibration output data | RMS values (average), Kurtosis, Crest Factor, Skewness, FFT High Energy samples (amplitude and frequency), and Sub-band Energy. | |||||||||||||||||||||||||||||||||||||||
| Vibration FFT no. of lines | 4096 (1.8 Hz resolution) | |||||||||||||||||||||||||||||||||||||||
| Vibration Raw data and full spectrum FFT data are available through the configuration application for further analysis by the users. | ||||||||||||||||||||||||||||||||||||||||
| Velocity measurement and range | Available as per ISO 10816-3, Range >0 to 100 mm/s | |||||||||||||||||||||||||||||||||||||||
| Triaxial accelerometer | MEMS, +/- 16g, 2500 Hz Bandwidth | |||||||||||||||||||||||||||||||||||||||
| Acoustics sensor | Bandwidth 20 to 20 kHz Maximum 120 dB SPL | |||||||||||||||||||||||||||||||||||||||
| Acoustics FFT data is available through a configuration application for further user analysis. | ||||||||||||||||||||||||||||||||||||||||
| Surface temperature | -40°C to +80°C (-40 °F to +176 °F) | |||||||||||||||||||||||||||||||||||||||
| Pressure sensor | 335 to 1100 hPa | |||||||||||||||||||||||||||||||||||||||
| Humidity | 0 to 100% RH | |||||||||||||||||||||||||||||||||||||||
| Edge computing | RMS, FFT calculations, Statistical parameters, RPM, Vibrational statistical parameter, and Static alarm thresholds2 | |||||||||||||||||||||||||||||||||||||||
| Operating temperature | -40°C to +80°C (-40 °F to +176 °F) | |||||||||||||||||||||||||||||||||||||||
| Data over LoRaWAN |
· Configurable publish rate of RMS values, Kurtosis, Crest Factor, and Skewness. · Configurable publish rate of FFT (36 High energy amplitudes). · Configurable Sub-band (size 250 Hz) energy values. |
|||||||||||||||||||||||||||||||||||||||
| Communication | · 2.4 GHz Bluetooth low energy. | |||||||||||||||||||||||||||||||||||||||
| Device LED indication |
· Green and Red LEDs |
|||||||||||||||||||||||||||||||||||||||
| Device diagnostics | Battery status, Sensor health | |||||||||||||||||||||||||||||||||||||||
| Battery life |
· Up to 3 years with 5 minutes sensor measurement interval and 30 mins LoRaWAN update. · Up to 51 years with 10 minutes sensor measurement interval and 60 mins LoRaWAN update. |
|||||||||||||||||||||||||||||||||||||||
| LoRaWAN reporting interval (all sensors data) | 1 minute to 24 hours | |||||||||||||||||||||||||||||||||||||||
| Vibration measurement duration | Acceleration RAW data – 2.2 seconds | |||||||||||||||||||||||||||||||||||||||
| Derived parameters | Velocity and RPM | |||||||||||||||||||||||||||||||||||||||
| Physical dimensions | W: 46 mm (1.81 inches) x H: 100 mm (3.93 inches) | |||||||||||||||||||||||||||||||||||||||
| Weight | 180 grams (0.39 lb) | |||||||||||||||||||||||||||||||||||||||
| Mounting options |
Adhesive Adapter Magnetic Adapter Screw Mount Adapter (M6 screw) Epoxy Mount Adapter |
|||||||||||||||||||||||||||||||||||||||
| Data logging | Capable of recording 20 days of data with the default configuration | |||||||||||||||||||||||||||||||||||||||
| Data security and encryption | AES256 LoRa and BLE encryption | |||||||||||||||||||||||||||||||||||||||
| Firmware updates | Available through the Honeywell Versatilis Connect App. | |||||||||||||||||||||||||||||||||||||||
| Wireless range | BLE 25m Line of Sight (LOS) and LoRa 4km Line of Sight (LOS) | |||||||||||||||||||||||||||||||||||||||
|
1 Change in default parameters will affect the battery life accordingly. 2 There will be an impact on battery life based on the number of times the alarm condition is created. |
||||||||||||||||||||||||||||||||||||||||
What Is It?
The Honeywell Versatilis™ Transmitter leverages the long-range, low-power LoRaWAN® technology to effectively transmit data about equipment status, environmental conditions, and gas emissions across extensive areas. Additionally, it features BLE connectivity for seamless and efficient setup and diagnostics.
How Does It Work?
The transmitters combine best-in-class MEMS (micro electro-mechanical system) based sensing technology with a low-power design, open secure wireless communication technologies, and user-friendly installation and operation.
What Problems Do They Solve?
Honeywell Versatilis™ Transmitters unlock the possibilities for condition-based monitoring for rotating equipment, including pumps, motors, compressors, fans, blowers, and gearboxes. Wide-ranging capabilities help customers reduce costs, improve safety, increase energy efficiency and comply with environmental regulations:
-
Digitising assets, processes and ambient conditions
-
Automating field data collection
-
Reducing unplanned downtime through predictive maintenance
-
Monitoring gaseous and fugitive emissions
